Custom MenuItem with Notification on it

Step 1: (build.gridle Module: app)

Add dependency

Compile ‘com.android.support:appcompact-v7:26.1.0’

Step 2: (values/styles.xml)

In styles.xml copy the current style and paste and change name of it and also change parent to NoActionBar i.e. parent="Theme.AppCompat.Light.DarkActionBar">

Note: This is important because we have to set ToolBas as our ActonBar so we should remove it by this style

<style name="noActionBar"
parent="Theme.AppCompat.Light.NoActionBar">

        <!-- Customize your theme here. -->

        <item name="colorPrimary">@color/colorPrimary</item>

        <item name="colorPrimaryDark">@color/colorPrimaryDark</item>

        <item name="colorAccent">@color/colorAccent</item>

    </style>

Step 3: (AndroidManifest.xml)

Set theme as our created style for our particular activity

<activity android:name=".YourActivity"
      android:theme="@style/noActionBar"/>

Then re-sync the Project

Step 4: (YourActivity.xml Layout)

1> Add ToolBar from AppCompact in Palette

Make sure That ToolBar is

<android.support.v7.widget.Toolbar />

Give id to it

android:id="@+id/my_toolbar"

Layout Code:

<android.support.v7.widget.Toolbar
    android:id="@+id/my_toolbar"
    android:layout_width="0dp"
    android:layout_height="wrap_content"
    android:layout_alignParentLeft="true"
    android:layout_alignParentStart="true"
    android:layout_alignParentTop="true"
    android:background="?attr/colorPrimary"
    android:fitsSystemWindows="true"
    android:minHeight="?attr/actionBarSize"
    android:theme="?attr/actionBarTheme"
    app:layout_constraintEnd_toEndOf="parent"
    app:layout_constraintStart_toStartOf="parent"
    app:layout_constraintTop_toTopOf="parent" />

2> Then Button and TextView to it

<Button
    android:id="@+id/add_to_cart_btn"
    android:layout_width="wrap_content"
    android:layout_height="wrap_content"
    android:layout_marginBottom="209dp"
    android:background="?selectableItemBackgroundBorderless"
    android:text="+"
    android:textSize="30sp"
    app:layout_constraintBottom_toBottomOf="parent"
    app:layout_constraintEnd_toEndOf="parent"
    app:layout_constraintStart_toStartOf="parent" />

<TextView
    android:id="@+id/countTv"
    android:layout_width="wrap_content"
    android:layout_height="wrap_content"
    android:layout_marginBottom="52dp"
    android:layout_marginEnd="36dp"
    android:text="0"
    android:textSize="30sp"
    app:layout_constraintBottom_toTopOf="@+id/add_to_cart_btn"
    app:layout_constraintEnd_toEndOf="@+id/add_to_cart_btn" />

Step 5: (drawable/rounded_textView.xml)

Then create drawable resource file named as rounded_textView.xml file add this code in it

By this we will create a shape to set it on TextView to show it as Circular TextView

<?xml version="1.0" encoding="utf-8"?>
    <shape xmlns:android="http://schemas.android.com/apk/res/android"
        android:shape="oval">

        <solid android:color="#FF5400" />
        <size
            android:height="20dp"
            android:width="20dp" />

    </shape>

Step 6: (drawable)

Download the icon for MenuItem from this site Link: https://material.io/icons/

And paste it in Drawable directory

Step 7: (Layout/cart_layout.xml)

Now create new layout resources file in layout directory

Named cart_layout

>And Add ImageButton and TextView on it

>And set Image Background as icon Downloaded and foreground as

android:foreground="?android:selectableItemBackground"

 to show animation when clicked

>And set background of textView as

android:background="@drawable/rounded_textview"

Code: (Layout/cart_layout.xml)

<?xml version="1.0" encoding="utf-8"?>
<RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:app="http://schemas.android.com/apk/res-auto"
    xmlns:tools="http://schemas.android.com/tools"
    android:layout_width="match_parent"
    android:layout_height="match_parent">

    <RelativeLayout
        android:id="@+id/relative_layout_cart_ic"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content">

        <ImageButton
            android:id="@+id/cart_ic_image"
            android:layout_width="40dp"
            android:layout_height="40dp"
            android:layout_alignParentLeft="true"
            android:layout_alignParentStart="true"
            android:layout_alignParentTop="true"
            android:layout_marginEnd="10dp"
            android:layout_marginLeft="10dp"
            android:layout_marginRight="10dp"
            android:layout_marginStart="10dp"
            android:layout_marginTop="5dp"
            android:background="@drawable/ic_shopping_cart_black_24dp"
            android:foreground="?android:selectableItemBackground" />

        <TextView
            android:id="@+id/count_tv"
            android:layout_width="wrap_content"
            android:layout_height="wrap_content"
            android:layout_alignTop="@+id/cart_ic_image"
            android:layout_centerHorizontal="true"
            android:background="@drawable/rounded_textview"
            android:gravity="center"
            android:text="0"
            android:textColor="@android:color/white"
            android:textSize="12sp"
            tools:layout_editor_absoluteX="32dp"
            tools:layout_editor_absoluteY="7dp" />


    </RelativeLayout>

</RelativeLayout>

Step 7: (menu/menu.xml)

Now Create new Directory in res named as menu

Note: menu directory is not present we have to create new manually

And in that menu directory create new menu resources file called

Menu.xml

And inside it write the below code:

<item
    android:id="@+id/cart_count_menu_item"
    app:showAsAction="always"
    app:actionLayout="@layout/cart_layout"
    android:title="Cart">
</item>

In app:actionLayout attribute we have set our layout which we have to inflate over our MenuItem

app:actionLayout="@layout/cart_layout"

Step 8: (YourActivity.xml Layout)

> Import Library only of v7 ToolBar i.e.

import android.support.v7.widget.Toolbar;

>Now in your Activity Create new Object for TextView Button and ToolBar and join them with kayout file

>And ya we have to call

setSupportActionBar()

method and pass ToolBar object to its parameter

>And setTitleTextColor to it

myToolBar.setTitleTextColor(0xFFFFFFFF);

Toolbar myToolBar;
Button addToCartBtn;
TextView countTv;

@Override
protected void onCreate(Bundle savedInstanceState) {
    super.onCreate(savedInstanceState);
    setContentView(R.layout.activity_main);

    myToolBar = findViewById(R.id.my_toolbar);
    setSupportActionBar(myToolBar);

    myToolBar.setTitleTextColor(0xFFFFFFFF);

    addToCartBtn=findViewById(R.id.add_to_cart_btn);
    countTv=findViewById(R.id.countTv);
}

Step 9: (YourActivity.xml Layout)

> Now Create new onCreateOptionMenu() method and Inflate our menu.xml to ToolBar by

getMenuInflater().inflate(R.menu.menu, menu);

> Now Create Global variable for MenuItem

MenuItem cartIconMenuItem;

> And Inflate the MenuItem by Menu.findItem() method

cartIconMenuItem = menu.findItem(R.id.cart_count_menu_item);

> Now create new variable for View and call MenuItem.getActionView() method to give

ActionView to view variable

View actionView = cartIconMenuItem.getActionView();

>Now check if actionView is not null in if statement

Code Snippet:

if (actionView != null) {


}

>Now in if condition inflate ImageButton and TextView to global variable of it

if (actionView != null) {
    countTvMenuItem=actionView.findViewById(R.id.count_tv);
    cartImageButtonwMenuItem=actionView.findViewById(R.id.cart_ic_image);
}

Note: For setting onClick on our custom MenuItem we have to set onClick on ImageButton Inflated, in onCreateOptionMenu() method

cartImageButtonwMenuItem.setOnClickListener(new View.OnClickListener() {
    @Override
    public void onClick(View view) {
        Intent intent = new Intent(MainActivity.this, ToolBarTest2.class);
        startActivity(intent);
    }
});

and return true or return super.onCreateOptionsMenu(menu);

Code of onCreateOptionMenu :

@Override
public boolean onCreateOptionsMenu(Menu menu) {
    getMenuInflater().inflate(R.menu.menu, menu);


    getSupportActionBar().setDisplayHomeAsUpEnabled(true);
    getSupportActionBar().setDisplayShowHomeEnabled(true);

    cartIconMenuItem = menu.findItem(R.id.cart_count_menu_item);
    View actionView = cartIconMenuItem.getActionView();

    if (actionView != null) {
        countTvMenuItem=actionView.findViewById(R.id.count_tv);
        cartImageButtonwMenuItem=actionView.findViewById(R.id.cart_ic_image);
    }


    cartImageButtonwMenuItem.setOnClickListener(new View.OnClickListener() {
        @Override
        public void onClick(View view) {
            Intent intent = new Intent(MainActivity.this, ToolBarTest2.class);
            startActivity(intent);
        }
    });


    return super.onCreateOptionsMenu(menu);
}

Step 10: (YourActivity.xml Layout)

Now create new Method in your activity class called onIncrement()

>And now create global variable of int count;

>And do increment of count in this method

>And set the Incremented number to TextView of ActionView and Activity TextView

Code doIncrease() Method:

private void doIncrease() {
        mCount++;
        countTv.setText(String.valueOf(mCount));
        countTvMenuItem.setText(""+mCount);

    }

Step 11: (YourActivity.xml Layout)

>Now call onDecrement() method in onClick of our Activity Button in onCreate

addToCartBtn.setOnClickListener(new View.OnClickListener() {
    @Override
    public void onClick(View view) {
        doIncrease();
    }
});

----Done----

MainActivity.java (Activity Java File)

import android.content.Context;

import android.support.v7.app.AppCompatActivity;

import android.os.Bundle;

import android.support.v7.widget.Toolbar;

import android.view.Menu;

import android.view.MenuItem;

import android.view.View;

import android.widget.Button;

import android.widget.ImageButton;

import android.widget.TextView;

import android.widget.Toast;

public class MainActivity extends AppCompatActivity {

    Toolbar mMyTollbar;

    Button mPlusBtn;

    ImageButton mImageBtn;

    TextView mActivityTv, mCountTv;

    MenuItem mCartIconMenuItem;

    int mCount = 0;

    Context mContext = MainActivity.this;

    @Override

    protected void onCreate(Bundle savedInstanceState) {

        super.onCreate(savedInstanceState);

        setContentView(R.layout.activity_main);

        mMyTollbar = findViewById(R.id.myToolBar);

        setSupportActionBar(mMyTollbar);

        mMyTollbar.setTitleTextColor(0xFFFFFFFF);

        mPlusBtn = findViewById(R.id.plus_btn);

        mActivityTv = findViewById(R.id.activity_tv);

        mPlusBtn.setOnClickListener(new View.OnClickListener() {

            @Override

            public void onClick(View view) {

                doIncrement();

            }

        });

    }

    @Override

    public boolean onCreateOptionsMenu(Menu menu) {

        getMenuInflater().inflate(R.menu.menu, menu);

        mCartIconMenuItem = menu.findItem(R.id.cart_count_menu_item);

        View actionView = mCartIconMenuItem.getActionView();

        if (actionView != null) {

            mCountTv = actionView.findViewById(R.id.count_tv_layout);

            mImageBtn = actionView.findViewById(R.id.image_btn_layout);

        }

        mImageBtn.setOnClickListener(new View.OnClickListener() {

            @Override

            public void onClick(View view) {

                Toast.makeText(mContext, "Image Button is Clicked!", Toast.LENGTH_LONG).show();

            }

        });

        return super.onCreateOptionsMenu(menu);

    }

    private void doIncrement() {

        mCount++;

        mCountTv.setText(String.valueOf(mCount));

        mActivityTv.setText(String.valueOf(mCount));

    }

}

activity_main.xml (Activity layout)

<?xml version="1.0" encoding="utf-8"?>

<RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"

    xmlns:app="http://schemas.android.com/apk/res-auto"

    xmlns:tools="http://schemas.android.com/tools"

    android:layout_width="match_parent"

    android:layout_height="match_parent" >

    <android.support.v7.widget.Toolbar

        android:id="@+id/myToolBar"

        android:layout_width="match_parent"

        android:layout_height="wrap_content"

        android:layout_alignParentLeft="true"

        android:layout_alignParentStart="true"

        android:layout_alignParentTop="true"

        android:background="?attr/colorPrimary"

        android:minHeight="?attr/actionBarSize"

        android:theme="?attr/actionBarTheme"

        tools:layout_editor_absoluteX="0dp"

        tools:layout_editor_absoluteY="0dp" />

    <Button

        android:id="@+id/plus_btn"

        android:layout_width="wrap_content"

        android:layout_height="wrap_content"

        android:layout_alignParentBottom="true"

        android:layout_centerHorizontal="true"

        android:layout_marginBottom="155dp"

        android:background="?attr/selectableItemBackgroundBorderless"

        android:text="+"

        android:textSize="30sp" />

    <TextView

        android:id="@+id/activity_tv"

        android:layout_width="wrap_content"

        android:layout_height="wrap_content"

        android:layout_centerHorizontal="true"

        android:layout_centerVertical="true"

        android:text="0"

        android:textSize="30sp" />

</RelativeLayout>

res/menu/menu.xml (menu Directories menu resources file)

<?xml version="1.0" encoding="utf-8"?>

<menu xmlns:android="http://schemas.android.com/apk/res/android"

    xmlns:app="http://schemas.android.com/apk/res-auto">

    <item

        android:id="@+id/cart_count_menu_item"

        android:title="Cart"

        app:actionLayout="@layout/cart_layout"

        app:showAsAction="always"></item>

</menu>

layouts/cart_layout.xml (Layout resources file for Inflating Cart MenuItem Layout)

<?xml version="1.0" encoding="utf-8"?>

<android.support.constraint.ConstraintLayout xmlns:android="http://schemas.android.com/apk/res/android"

    xmlns:app="http://schemas.android.com/apk/res-auto"

    xmlns:tools="http://schemas.android.com/tools"

    android:layout_width="match_parent"

    android:layout_height="match_parent">

    <RelativeLayout

        android:layout_width="wrap_content"

        android:layout_height="wrap_content">

        <ImageButton

            android:id="@+id/image_btn_layout"

            android:layout_width="40dp"

            android:layout_height="40dp"

            android:layout_margin="10dp"

            android:background="@drawable/ic_shopping_cart_black_24dp"

            android:foreground="?attr/selectableItemBackgroundBorderless"

            tools:layout_editor_absoluteX="7dp"

            tools:layout_editor_absoluteY="16dp" />

        <TextView

            android:id="@+id/count_tv_layout"

            android:layout_width="wrap_content"

            android:layout_height="wrap_content"

            android:layout_alignParentTop="true"

            android:layout_centerHorizontal="true"

            android:layout_marginTop="11dp"

            android:background="@drawable/rounded_textview"

            android:gravity="center"

            android:text="0"

            android:textColor="@android:color/background_light"

            android:textSize="12sp" />

    </RelativeLayout>

</android.support.constraint.ConstraintLayout>

res/drawable/rounded_textview.xml (drawable resources file for textView background shape)

<?xml version="1.0" encoding="utf-8"?>

<shape xmlns:android="http://schemas.android.com/apk/res/android"

    android:shape="oval">

    <solid android:color="#FF5400"/>

    <size

        android:width="20dp"

        android:height="20dp"/>

</shape>

res/values/styles.xml (values default style.xml file code)

<resources>

    <!-- Base application theme. -->

    <style name="AppTheme" parent="Theme.AppCompat.Light.DarkActionBar">

        <!-- Customize your theme here. -->

        <item name="colorPrimary">@color/colorPrimary</item>

        <item name="colorPrimaryDark">@color/colorPrimaryDark</item>

        <item name="colorAccent">@color/colorAccent</item>

    </style>

    <style name="noActionBar" parent="Theme.AppCompat.Light.NoActionBar">

        <!-- Customize your theme here. -->

        <item name="colorPrimary">@color/colorPrimary</item>

        <item name="colorPrimaryDark">@color/colorPrimaryDark</item>

        <item name="colorAccent">@color/colorAccent</item>

    </style>

</resources>
